Maretron Mini Bulk Cable 100m Blue #NB1-100C
-80%

Maretron Mini Bulk Cable 100m Blue #NB1-100C

Original price was: $657.55.Current price is: $131.51.

SKU: GPH542481 Category: Tag:
Trust Badge Image

Description

Maretron NB1-100C Network Accessories

Maretron Mini Bulk Cable – 100 Meter – Blue
Specifications

Overall

  • Outer Jacket Mat/Color:PVC/Blue – NB1, PVC/Gray – NG1
  • Insulation Material: PE (data), PVC (power)
  • Construction: 2×15 (1.45mm) AWG, 2×18 (1.02mm) AWG, 18 (1.02mm) AWG Drain Wire
  • Shielding (3 Levels): Foil (overall), Foil (power pair), Foil (data pair)

    Power Pair

  • Wire: 2×15 (1.45mm) AWG
  • Resistance/Conductor: 3.44 Ohms/1000 ft max
  • Max Amperage:16 Amps – NB1, 14 Amps – NG1
  • Color Code: Red/Black

    Data Pair

  • Wire: 2×18 (1.02mm) AWG
  • Characteristic Impedance: 120 Ohms +/- 10%
  • Capacitance: 12 pF/1000 ft Max
  • Color Code: White/Blue

    Approvals

  • UL: PLTC 75 deg C Sunlight Resistant E90625, AWM 80 deg C 300V
  • CSA: CMX-OUTDOOR-CMG LL54185 75 deg C, AWM I/II A/B 80 deg C 300V FT4
  • NMEA: NMEA 2000 APPROVED
  • IEC: IEC-61162-3

    Specifications:

    Load Equivalence # (LEN) = NONE

    Normalized SKU: NB1100C

    UPC Code: 873804003047
